Table 2-8
Table: Parameters of the SIOM-P40-300 Module
Model Parameter Specifications
SIOM-P40-
300
Size (WxDxH
)
390mm x 415mm (the depth of the lever not
included) x 35mm
Weight 5.65kg
Port 2 QSFP+ ports (40GE), 12 SFP+ ports
(10GE)
Memory 64GB
Flash Memory 8GB
LED Indicator 1 PWR LED Indicator
1 STA LED Indicator
Every optical port has 1 LINK LED Indicator
and 1 ACT LED Indicator
SIOM-P100-300
SIOM-P100-300 is compatible with SG-6000-X10800. The 3D diagram and specifications of the
SIOM-P100-300 are shown below.
Figure 2-9
Fig: 3D Diagram of the SIOM-P100-300 Module
Preface 21
