Hardware Parameters
Hardware parameters of SG-6000-X10800 are shown below:
Table 2-2
Table: SG-6000-X10800 Hardware Parameters
Parameter Description
Chassis 18U
Size (W×D×H) 442.0mm x 715.0mm (the depth of the lever not included) x 797.0mm
Weight Net weight: 114.9kg (with fan trays included)
Gross weight: 165.0kg (with accessories and all packaging included)
Ambient Tem-
perature
0℃-40℃
Relative Humidity 10%-95% (non-condensing)
Front Panel
Hillstone SG-6000-X10800 front panel consists of twelve general expansion slots, two fan trays,
two ESD points, two rack-mounting ears, one air inlet, and several LED indicators (one PWR,
one STA, one ALM, one HA, two FANs).
Figure 2-1
Fig: 3D Diagram of the SG-6000-X10800 Front Panel
Preface 11
