Model TRAN-SX
TRAN-
LX10
TRAN-LX40 TRAN-LX80
Dara Rate 1.25Gbps 1.25Gbps 1.25Gbps 1.25Gbps
Connector Type LC LC LC LC
Fiber Mode (SMF/MMF) 62.5/125μm
MMF
9/125μm
SMF
9/125μm
SMF
9/125μm
SMF
Max Transmission
Distance
0.3km 10km 40km 80km
Center Wavelength 850nm 1310nm 1310nm 1550nm
Power dissipation
(W/mW)
<500mW <600mW <700mW <700mW
Transmit Power (dBm) -9.5～-2.5 -9.5～-3.0 0～5.0 0～5.0
Max Receiver Sensitivity
(dBm)
-13.5 -14.5 -21 -14.5
Overload Power (dBm) 0 0 0 0
Extinction Ratio (dB) 9 9 9 9
Operating Case Tem-
perature
-40ºC-85ºC -40ºC-85ºC -10ºC-70ºC -10ºC-70ºC
Hot-swappable Yes Yes Yes Yes
1GE(SFP) Copper SFP Module
To connect devices via the copper SFP module, use the crossover cable or the standard cable.
The model of Hillstone copper SFP is TRAN-GC, whose specifications are listed below.
