Tips: For more information about the FAN LED indicators on the front panel, see
LED Indicators.
Back Panel
SG-6000-X9180 back panel consists of four power supply slots (PS0-PS3), two SWM slots
(SWM0 and SWM1), and two SCM slots (SCM0 and SCM1), one fan tray, one ESD point, one
power switch, one CLR button, and two grounding screws.
Figure 2-18
Fig: 3D Diagram of the SG-6000-X9180 Back Panel
