Tips: For more information about the FAN LED indicators on the front panel, see
LED Indicators.
Back Panel
SG-6000-X10800 back panel consists of eight power supply slots (PS0-PS7), two SWM slots
(SWM0 and SWM1), and two SCM slots (SCM0 and SCM1), one ESD point, one power switch,
one CLR button, two grounding screws, and air outlets.
Figure 2-3
Fig: 3D Diagram of the SG-6000-X10800 Back Panel
Figure 2-4
Fig: Front View of the SG-6000-X10800 Back Panel
