Model Parameter Specifications
SIOM-P100-
260
Size (WxDxH ) 434mm x 335mm (the depth of the lever not
included) x 35mm
Weight 5.60kg
Port 2 QSFP28 ports (100GE)
16 SFP+ ports (10GE)
Memory 96GB (DDR4)
Flash Memory 16GB
LED Indicators 1 PWR LED Indicators
1 STA LED Indicators
Every optical port has 1 LINK LED Indicator and
1 ACT LED Indicator
SIOM-P100H-260
SIOM-P100H-260 is compatible with SG-6000-X8180. The 3D diagram and specifications of the
SIOM-P100H-260 are shown below.
Figure 2-37
Fig: 3D Diagram of the SIOM-P100H-260 Module
62
