Hillstone SG-6000 X-Series User Manual

Expansion Modules
SG-6000-X7180 requires at least one SCM, one SSM, and one IOM to function normally.
SG-6000-X7180 supports the following expansion modules:
l SCM: SCM-100
l SSM: SSM-200, SSM-100
l QSM: QSM-200, QSM-100
l IOM: IOM-16SFP-100 , IOM-4XFP-100, IOM-2Q8SFP+-200, IOM-2Q8SFP+, IOM-
8SFP+
l Bypass Modules: IOM-2SM-BE, IOM-2MM-BE
SCM-100
The 3D diagram and specifications of the SCM-100 module are shown below.
Figure 2-47 Fig: 3D Diagram of the SCM-100 Module
Table 2-33 Table: Parameters of the SCM-100 Module
Preface 77
