Hillstone SG-6000 X-Series User Manual

LED Color/Status Description
failed so the expansion module is down.
Off The expansion module is powered off.
STA Green/Always
on
The expansion module is booting.
Green/Blinking The expansion module is running normally.
Red/Always on The expansion module failed to boot or an expansion
module exception occurred.
INLINE Green/Blinking The bypass module is working in the inline mode.
Green/Always
on
The bypass module is working in the bypass mode.
Orange/Always
on
The bypass module is working abnormally.
Red/Always on The device is working abnormally and the bypass
module is working in the bypass mode.
Off The bypass module is not powered and it is in the
bypass mode.
Notes: LED indicators on different expansion modules vary. Please refer to the
actual expansion module.
Power Supply Module
SG-6000-X8180 supports the AC power module and DC power module. You can power the
device by installing AC or DC power modules as needed and then connecting them to the cor-
responding external power supply. You should install at least one (in the country or region where
the standard voltage is 110V, at least two) 220V AC or one -48V DC power modules to power
the device.
68
