Hillstone SG-6000 X-Series User Manual

Model TRAN-XFP-SR TRAN-XFP-LR
TRAN-XFP-
LX40
TRAN-XFP-
LX80
(W/mW)
Transmit Power
(dBm)
-2.8～-1.5 -6.0～-1.0 -1.0～+2.0 0～+4.0
Max Receiver Sens-
itivity (dBm)
-7.5 -10.3 -11.3 -22.5
Overload Power
(dBm)
0.5 0.5 2.0 4.0
Extinction Ratio
(dB)
3.0 6 8.2 9.0
Operating Case
Temperature
-5ºC-70ºC -5ºC-75ºC -5ºC-75ºC 0ºC-70ºC
Hot-swappable Yes Yes Yes Yes
QSFP+ Port
The modules supported by SG-6000 X series (IOM-2Q8SFP+ -200, IOM-2Q8SFP+, IOM-P40-
300, and SIOM-P40-300) are designed with two 40GE(QSFP+) ports.
Table 2-57 Table: QSFP+ Port Attribute
Attribute Description
Connector
Type
QSFP+
Frame Format Ethernet_II
Ethernet_SNAP
110
