Table 2-28
Table: Parameters of the SIOM-P100H-260 Module
Model Parameter Specifications
SIOM-P100H-
260
Size (WxDxH ) 434mm x 335mm (the depth of the lever not
included) x 35mm
Weight 5.80kg
Port 4 QSFP28 ports (100GE)
16 SFP+ ports (10GE)
Memory 96GB (DDR4)
Flash Memory 16GB
LED Indicators 1 PWR LED Indicator
1 STA LED Indicator
Every optical port has 1 LINK LED Indicator and
1 ACT LED Indicator
Notes: SG-6000-X8180 devices cannot be downgraded to versions lower than
StoneOS 5.5R8P0.1. Otherwise, the SIOM module will not be recognized by the
system.
IOM-8MM-B-260
IOM-8MM-B-260 is a type of multi-mode Bypass module. The 3D diagram and specifications of
the IOM-8MM-B-260 are shown below.
Figure 2-38
Fig: 3D Diagram of the IOM-8MM-B-260 Module
