l If an HVDC power supply is used, connect it to the AC power module.

Power Module Diagram

The AC power module and DC power module compatible with SG-6000-X8180 are shown

below.

Figure 2-39

Fig: AC Power Module (C14 Connector)

Figure 2-40

Fig: DC Power Module
