Parameter Description
Weight Net weight: 59.0kg (with fan trays included)
Gross weight: 73.5kg (with accessories and all packaging included)
Ambient Tem-
perature
0℃-40℃
Relative Humidity 10%-95% (non-condensing)
Front Panel
Hillstone SG-6000-X9180 front panel consists of six general expansion slots, two handles, two
rack-mounting ears, two air inlet, one fan tray, one cable rack, one ESD point, and several LED
indicators (one PWR, one STA, one ALM, and one HA).
Figure 2-16
Fig: 3D Diagram of the SG-6000-X9180 Front Panel
Figure 2-17
Fig: Front View of the SG-6000-X9180 Front Panel
Preface 33
