Power Module
Type
Input Voltage Range of
the External Power Sup-
ply
Maximum Output
Power of the AC
Power Module
Number of Power Mod-
ules Required for
Normal Device Run-
ning
HVDC voltage: 192 ~
288V DC
1600W At least 2
DC power module -36 ~ -72V DC 1100W At least 2
Notes:
l To ensure the redundant backup of the power modules, install as many power
modules as you are allowed to.
l Mixed use of AC and DC power supply modules in one device is not sup-
ported.
l If an HVDC power supply is used, connect it to the AC power module.
Power Module Diagram
The AC power module and DC power module compatible with SG-6000-X9180 are shown
below.
Fig: AC Power Module (C14 Connector)
50
