Table 2-29
Table: Parameters of the IOM-8MM-B-260 Module
Model Parameter Specifications
IOM-8MM-B-
260
Size (WxDxH ) 434mm x 335mm ( with the depth of lever
included) x 35mm
Weight 3.0KG
Port 16 LC-type optical ports (supporting multi-
mode 10G, 40G, and 100G)
INLINE LED Indic-
ator
4
Instructions for Using IOM-8MM-B-260
IOM-8MM-B-260 module has 16 optical ports which can group four Bypass pairs, including pair0
(port 0' and port 1'), pair1 (port 2' and port 3'), pair2 (port 4' and port 5') and pair3 (port 6' and
port 7').
In the global configuration mode, use the following command to enter the Bypass interface pair
mode:
bypass slot
slot-id
pair
pair-id
64
