SWM-300
SWM-300 is compatible with SG-6000-X10800. The 3D diagram and specifications of the SWM-
300 are shown below.
Figure 2-11
Fig: 3D Diagram of the SWM-300 Module
Table 2-11
Table: Parameters of the SWM-300 Module
Model Parameter Specifications
SWM-300 Size (WxDxH
)
440mm x 215mm (the depth of the lever not
included) x 45mm
Weight 3.20kg
Port None
Memory None
LED Indicator 1 PWR LED Indicator
1 STA LED Indicator
LED Indicators
The following table describes LED indicators of SG-6000-X10800.
Table 2-12
Table: Description of the SG-6000-X10800 LED Indicators
