Model
TRAN-SR-
SFP+
TRAN-LR-
SFP+
TRAN-SFP+-
LX40
TRAN-
SFP+-
LX80
Form Factors SFP+ SFP+ SFP+ SFP+
Interface Specification 10GBase-SR 10GBase-LR 10GBase-ER 10GBase-
ZR
IEEE Standard IEEE 802.3
Clause 52
IEEE 802.3ae IEEE 802.3ae IEEE
802.3-
2008
Clause 52
Dara Rate 10Gbps 10Gbps 10Gbps 10Gbps
Connector Type LC LC LC LC
Fiber Mode (SMF/MMF) 50/125μm
MMF
9/125μm
SMF
9/125μm
SMF
9/125μm
SMF
Max Transmission
Distance
0.3km 10km 40km 80km
Center Wavelength 850nm 1310nm 1550nm 1550nm
Power dissipation
(W/mW)
450mW <1.0W <1.5W <1.2W
Transmit Power (dBm) -7.3～+6.0 -8.2～+0.5 -4.7～+4.0 0～+4.0
Max Receiver Sensitivity
(dBm)
-7.5 -10.3 -11.3 -24
Overload Power (dBm) 6.0 +0.5 -1.0 4.0
