SCM-300
SCM-300 is compatible with SG-6000-X10800. The 3D diagram and specifications of the SCM-
300 module are shown below.
Figure 2-5
Fig: 3D Diagram of the SCM-300 Module
Table 2-3
Table: Parameters of the SCM-300 Module
Model Parameter Specifications
SCM-300 Size (WxDxH
)
440mm x 215mm (the depth of the lever not
included) x 45mm
Weight 3.45kg
Port 1 Console port (CON port)
1 Auxiliary port (AUX port)
1 USB 2.0 Host port
1 Management Port (MGT Port)
2 HA ports (HA0 and HA1)
Memory 32GB
Flash Memory 64GB
LED Indicator 1 PWR LED Indicator
Preface 15
