Table 2-4
Table: Parameters of the SSM-300 Module
Model Parameter Specifications
SSM-300 Size (WxDxH
)
390mm x 415mm (the depth of the lever not
included) x 35mm
Weight 5.70kg
Port None
Memory 128GB
Flash Memory 8GB
LED Indicator 1 PWR LED Indicator
1 STA LED Indicator
QSM-300
QSM-300 is compatible with SG-6000-X10800. The 3D diagram and specifications of the QSM-
300 are shown below.
Figure 2-7
Fig: 3D Diagram of the QSM-300 Module
Preface 17
