Model Parameter Specifications
and 1 ACT LED Indicator
SWM-280
SWM-280 is compatible with SG-6000-X9180. The 3D diagram and specifications of the SWM-
280 are shown below.
Figure 2-25
Fig: 3D Diagram of the SWM-280 Module
Table 2-20
Table: Parameters of the SWM-280 Module
Model Parameter Specifications
SWM-280 Size (WxDxH ) 300mm x 260mm (the depth of the lever not
included) x 45mm
Weight 3.40kg
Port None
Memory None
LED Indicator 1 PWR LED Indicator
1 STA LED Indicator
Preface 45
