SCM-260
SCM-260 is compatible with SG-6000-X8180. The 3D diagram and specifications of the SCM-
260 are shown below.
Figure 2-33
Fig: 3D Diagram of the SCM-260 Module
Table 2-24
Table: Parameters of the SCM-260 Module
Model Parameter Specifications
SCM-260 Size (WxDxH ) 163mm x 230mm (the depth of the lever not
included) x 40mm
Weight 1.10kg
Port 1 Console port (CON port)
1 USB 2.0 Host port
1 Management Port (MGT Port)
2 HA ports (HA0 and HA1)
Memory 8GB (DDR4)
Flash Memory 64GB
LED Indicator 1 PWR LED Indicator
Preface 57
