Hioki 3197 User Manual

Confirming Package Contents
2
Confirming Package Contents
 Instruction Manual.............................1
 Measurement Guide .........................1
 PC application program for Model 3197
(CD) .................................................. 1
 Model 3197 Power Quality Analyzer
Confirm that these contents are provided.
Accessories
When you receive the instrument, inspect it carefully to ensure that no damage
occurred during shipping. In particular, check the accessories, panel switches,
and connectors. If damage is evident, or if it fails to operate according to the
specifications, contact your dealer or Hioki representative.
 9418-15 AC Adapter
(AC power cord included).................. 1
 9459 Battery Pack ............................ 1
L9438-55 Voltage Cord
(Four black voltage cords)..........1 set
 USB Cable........................................ 1
 Carrying Case................................... 1
Install these on the instrument before oper-
ating (p. 37)
 Measurement lead labels..........1 sheet
(For channel identification of the voltage measure-
ment and clamp sensor leads)
 Input terminal labels .................1 sheet
(Apply the appropriate labels around the input termi-
nals according to usage)
 Strap ....................................................
(p. 38)
(p. 37)
(p. 38)

Hioki 3197 Specifications

General

Model	Hioki 3197
Category	Power Quality Analyzer
Harmonic Measurement	Up to 50th order
Display	LCD
Interface	RS-232C
Power Supply	100 to 240 V AC, 50/60 Hz
Measurement Category	CAT III 600 V
Current Measurement Range	With clamp sensor, up to 5000 A
Frequency Measurement Range	40 Hz to 70 Hz
Frequency Range	40 Hz to 70 Hz
