2.5 Internal Operating Status and Memory Usage
34
How data is recorded to internal memory (internal operating status)
depends on whether memory partitioning is enabled.
2.5 Internal Operating Status and Memory
Usage
When Memory Partitioning is Disabled (Partition: [OFF])
Start and Stop Recording Manually
Measurement at Specified Start and Stop Times
:starts and stops recording.
[SET]
[RECORDING]
[ANALYZE]
• If you press the key after a preset start time, "Operation Error!" is displayed.
• If you press the key while
[WAITING] and before a preset start time, recording is
aborted.
Unless Interval: AUTO is selected,
measurement starts at a suitable
interval multiple.
[SET] [WAITING] [ANALYZE][RECORD-
ING]
Start Time
Stop Time
Erase and return to
[SET]:
To erase and return to
[SET]:
To return to [ANALYZE]:
Stop
Recording?
Back to [ANALYZE]:

Hioki 3197 Specifications

General

Model	Hioki 3197
Category	Power Quality Analyzer
Harmonic Measurement	Up to 50th order
Display	LCD
Interface	RS-232C
Power Supply	100 to 240 V AC, 50/60 Hz
Measurement Category	CAT III 600 V
Current Measurement Range	With clamp sensor, up to 5000 A
Frequency Measurement Range	40 Hz to 70 Hz
Frequency Range	40 Hz to 70 Hz
