4.4 Setting Event Detection [REC&EVENT]
68
By enabling Start/Stop Events, measurements are recorded as an event
each time recording is started and stopped.
Manual event recording records the measurement state at the current time
as
an event.
Press the key to display the [REC&EVENT] screen.
Timed Event
Records events at specified
time intervals.
Voltage Swell, Dip and
Interruption
Any momentary deviation
of rms voltage from the nom-
inal voltage is recorded as an
event.
Opening the [REC&EVENT] Screen
Inrush Event
(Inrush, Starting or
Surge Current)
An event is recorded
when the specified value
is exceeded.
Transient Event
(Transient Overvolt-
age)
An event is recorded
when high frequency im-
pulse noise is imposed on
the mains voltage wave-
form.
Start Event/ Stop Event
Manual Events
The time of a manual event is the moment at
which these keys are pressed simultaneously.
Manual event recording is always enabled.
See: "Manual" (p. 113)
To Next Page
