Appendix 3 3197 Data-header Composition
A 7
A
Appendix 3 3197 Data-header Composition
Classifica-
tion
Header Explanation
Date
Time
Status
Date Date
Time Time
Status
Status
TIME PLOT
DIP/SWELL
Umax1, Umax2, Umax3 Voltage (1/2) Maximum value
Umin1, Umin2, Umin3
Voltage (1/2) Minimum value
TIME PLOT
RMS
Maximum
Values
MaxFreq Frequency
MaxUrms1, MaxUrms2, MaxUrms3 Voltage
MaxU+peak1, MaxU+peak2, MaxU+peak3 Voltage Waveform Peak+
MaxU-peak1, MaxU-peak2, MaxU-peak3 Voltage Waveform Peak-
MaxIrms1, MaxIrms2, MaxIrms3, MaxIrms4 Current
MaxI+peak1, MaxI+peak2, MaxI+peak3, MaxI+peak4 Current Waveform Peak+
MaxI-peak1, MaxI-peak2, MaxI-peak3, MaxI-peak4 Current Waveform Peak-
MaxUave Voltage for 3phase
MaxIave Current for 3phase
MaxPsum, MaxSsum, MaxQsum
Active Power, Apparent Power, Reac-
tive Power
MaxPFsum, MaxUunb Power Factor
MaxUthd1, MaxUthd2, MaxUthd3
Total Harmonic Voltage Distortion Ratio
TIME PLOT
RMS
Minimum
Values
MinFreq Frequency
MinUrms1, MinUrms2, MinUrms3 Voltage
MinU+peak1, MinU+peak2, MinU+peak3 Voltage Waveform Peak+
MinU-peak1, MinU-peak2, MinU-peak3 Voltage Waveform Peak-
MinIrms1, MinIrms2, MinIrms3, MinIrms4 Current
MinI+peak1, MinI+peak2, MinI+peak3, MinI+peak4 Current Waveform Peak+
MinI-peak1, MinI-peak2, MinI-peak3, MinI-peak4 Current Waveform Peak-
MinUave Voltage for 3phase
MinIave Current for 3phase
MinPsum, MinSsum, MinQsum
Active Power, Apparent Power,
Reactive Power
MinPFsum, MinUunb Power Factor
MinUthd1, MinUthd2, MinUthd3
Total Harmonic Voltage Distortion Ratio
TIME PLOT
RMS
Average
Values
AveFreq Frequency
AveUrms1, AveUrms2, AveUrms3 Voltage
AveU+peak1, AveU+peak2, AveU+peak3 Voltage Waveform Peak+
AveU-peak1, AveU-peak2, AveU-peak3 Voltage Waveform Peak-
AveIrms1, AveIrms2, AveIrms3, AveIrms4 Current
AveI+peak1, AveI+peak2, AveI+peak3, AveI+peak4 Current Waveform Peak+
AveI-peak1, AveI-peak2, AveI-peak3, AveI-peak4 Current Waveform Peak-
AveUave Voltage for 3phase
AveIave Current for 3phase
AvePsum, AveSsum, AveQsum
Active Power, Apparent Power,
Reactive Power
AvePFsum, AveUunb Power Factor
AveUthd1, AveUthd2, AveUthd3
Total Harmonic Voltage Distortion Ratio
TIME PLOT
Energy
Quadergy
WP+, WP- Energy (Delivered, Received)
WQ_LAG, WQ_LEAD Quadergy (Lagging, Leading)
