Hioki 3197 User Manual

95
6
The three data display screen types are called [VIEW], [TIME PLOT] and
[EVENT].
Viewing Data Chapter 6
Viewing Instantaneous Data
(displays the measurement status about once per second)
Screen Display Setting Contents Ref.
VIEW
[WAVEFORM]
[VECTOR]
[HARMONICS]
[DMM]
Displays instantaneous measure-
ment values.
Measurement data can be viewed at
a
ny time regardless of recording start
or stop state.
"6.1 Viewing Instanta-
neous Data (VIEW
Screen)" (p. 96)
View Recording Data
(displays the current recording conditions or recorded results)
TIME PLOT
[RMS]
[DIP/SWELL]
[DEMAND]
[ENERGY]
Displays data at each measurement
i
nterval as a time series graph.
Shows fluctuations that occur be-
tween recording start and stop.
"6.2 Displaying a Time
Series Plot (TIME PLOT
screen)" (p. 102)
EVENT
[WAVEFORM]
[DETAILS]
[RMS WAVE]
[INRUSH]
Displays the results of event detec-
tion.
Shows the contents of events detect-
ed between recording start and stop.
"6.3 Viewing Anomalous
Phenomena (EVENT
screen)" (p. 108)

Hioki 3197 Specifications

General

Model	Hioki 3197
Category	Power Quality Analyzer
Harmonic Measurement	Up to 50th order
Display	LCD
Interface	RS-232C
Power Supply	100 to 240 V AC, 50/60 Hz
Measurement Category	CAT III 600 V
Current Measurement Range	With clamp sensor, up to 5000 A
Frequency Measurement Range	40 Hz to 70 Hz
Frequency Range	40 Hz to 70 Hz
