Hioki 3197 User Manual

Introduction
1
Thank you for purchasing the HIOKI Model 3197 Power Quality Ana-
lyzer. To obtain maximum performance from the instrument, please read
this manual carefully, and keep it handy for future reference.
In this document, the “instrument” means the Model 3197 Power Quality
Analyzer.
Optional clamp-on sensors (or clamp-on leakage sensors (p. 3)) are
required to measure current with this instrument. These are called clamp
sensors in the rest of this manual.
Refer to the manual provided with the clamp sensors for details.
Registered trademarks
• Windows is a registered trademark of Microsoft Corporation in the
United States and/or other countries.
• Sun, Sun Microsystems and Java are trademarks or registered trade-
marks of Sun Microsystems, Inc. in the USA and other countries.
• Adobe and Reader are either registered trademarks or trademarks of
Adobe Systems Incorporated in the United States and/or other coun-
tries.
Introduction

Hioki 3197 Specifications

General

Model	Hioki 3197
Category	Power Quality Analyzer
Harmonic Measurement	Up to 50th order
Display	LCD
Interface	RS-232C
Power Supply	100 to 240 V AC, 50/60 Hz
Measurement Category	CAT III 600 V
Current Measurement Range	With clamp sensor, up to 5000 A
Frequency Measurement Range	40 Hz to 70 Hz
Frequency Range	40 Hz to 70 Hz
