Appendix 5 Power Range Structure
A 9
A
The range structure tables indicate the full-scale display value of each measurement range.
The power range indicates summed values, with the 1P2W power range applicable to each
channel
regardless of the actual wiring configuration.
The range structure of Apparent Power (S) and Reactive Power (Q) are the same, but in
units of VA and var, respectively.
Appendix 5 Power Range Structure
Power Range Structure Table 1
Current Range
Using Model 9657-10 or
9675 (100 mV/A)
Using Model 9694 or
9695-02 (10 mV/A)
Using Model 9660 or
9695-03 (5 mV/A)
Voltage
Range
Wiring
Configuration
500.0mA 5.000A 5.000A 50.00A 10.00A 100.0A
600.0V
1P2W 300.0W 3.000kW 3.000kW 30.00kW 6.000kW 60.00kW
1P3W
3P3W2M
600.0W 6.000kW 6.000kW 60.00kW 12.00kW 120.0kW
3P3W3M,
3P4W,
3P4W2.5E
900.0W 9.000kW 9.000kW 90.00kW 18.00kW 180.0kW
Power Range Structure Table 2
Current Range
Using Model 9661 or 9667
in 500A range (1 mV/A)
Using Model 9669
(0.5 mV/A)
Using Model 9667 in 5 kA
range (0.1 mV/A)
Voltage
Range
Wiring
Configuration
50.00A 500.0A 100.0A 1.000kA 500.0A 5.000kA
600.0V
1P2W 30.00kW 300.0kW 60.00kW 600.0kW 300.0kW 3.000MW
1P3W
3P3W2M
60.00kW 600.0kW 120.0kW 1.200MW 600.0kW 6.000MW
3P3W3M,
3P4W,
3P4W2.5E
90.00kW 900.0kW 180.0kW 1.800MW 900.0kW 9.000MW
