Hioki 3197 User Manual

Contents
i
1
2
3
4
5
6
7
8
9
A
Index
Contents
Introduction.................................................................................1
Confirming Package Contents....................................................2
Safety Information ......................................................................4
Operating Precautions................................................................7
Operating Procedure Descriptions in this Manual....................12
Chapter 1
Overview ____________________________________13
1.1 Product Overview .......................................................13
1.2 Features .....................................................................14
1.3 Measurement Flowchart .............................................17
 Initial instrument preparations ...................................................19
 Install and connect the instrument, and turn the power on .......19
 Other preparations ....................................................................19
 Confirming Instrument Settings and Connecting to the Lines to
be Measured .............................................................................20
 Start recording and analyze recorded measurement data. .......21
Chapter 2
Names and Functions of Parts and
Basic
Setup ________________________________________23
2.1 Panel and Operating Keys .........................................23
2.2 Basic Operations ........................................................27
2.3 Screen Configurations ................................................28
2.4 Common Screen Elements ........................................32
2.5 Internal Operating Status and Memory Usage ...........34
 When Memory Partitioning is Disabled (Partition: [OFF]) .........34
 Using Memory Partitioning (Partition: [ON]) ..............................35
Chapter 3
Measurement Preparations _________________37
3.1 Initial Instrument Preparations ...................................37
 Apply the appropriate label to the input terminals .....................37
 Apply the appropriate labels to the voltage measurement and
clamp sensor leads ...................................................................38
 Attach the strap .........................................................................38

Hioki 3197 Specifications

General

Model	Hioki 3197
Category	Power Quality Analyzer
Harmonic Measurement	Up to 50th order
Display	LCD
Interface	RS-232C
Power Supply	100 to 240 V AC, 50/60 Hz
Measurement Category	CAT III 600 V
Current Measurement Range	With clamp sensor, up to 5000 A
Frequency Measurement Range	40 Hz to 70 Hz
Frequency Range	40 Hz to 70 Hz
