6.3 Viewing Anomalous Phenomena (EVENT screen)
116
The Event List
Item Example Description Details
Event Number 3 Event Number Displays from 1 to 50.
Date 10/03 Month/Day
Time 13:49:11.320 Hour:Min:Sec 1 ms resolution
Event Type
START Start
STOP Stop
MANUAL Manual
TIMER Timer
SWELL Voltage Swell
DIP Voltage Dip
INTER. Interruption
TRANSIENT Transient Overvoltage
INRUSH Inrush Current
Channels
CH1 Channel 1
Displayed for voltage swell, dip
an
d interruption
CH2 Channel 2
CH3 Channel 3
IN/OUT
IN EVENT IN (Onset)
Displayed for voltage swell, volt-
age dip, interruption and transient
o
vervoltage
OUT
EVENT OUT
(recovery)
Graph indicators
*U
Voltage Fluctuation
Gr
aph
Indicates analysis is available on
the voltage fluctuation screen
*I Inrush Current Graph
Indicates analysis is available on
t
he inrush current screen
Refer to the “Event Detail List” for details about contents for multiple events (p. 118).
