8.3 Event Specifications
151
8
Timer
Measurement
method
Detect events at preset intervals
Timer event
interval
OFF, 1, 5, 15 or 30 minutes; 1, 2 or 12 hours; or 1 day
Detection criteria Occurrence time
Recording
contents
Event data, event waveform
Event data format Event number, date, time, event type
Manual
Measurement
method
Detect events when keys are pressed (pressing the
[ESC] and [EVENT] keys at the same time)
Recording
contents
Event data, event waveform
Event data format Event number, date, time, event type
Start, Stop
Measurement
method
Recording start and stop operations are detected as
events
Recording
contents
Event data, event waveform,
Event data format Event number, date, time, event type
Event Type
Event Detection
Event detection method
Detection by ORing each event type
Event setting
Events other than manual events, and start/stop can be enabled/
disabled (set on/off)
Event waveform recording
length
Waveform from 20 ms before detection + 200 ms upon detection + 30
ms after detection
Event voltage fluctuation
graph length
0.5 s before + 2.5 s after detection
Inrush current graph
length
0.5 s before + 29.5 s after detection
Maximum event count
1000
Maximum recording event
number
50 event waveforms
20 event voltage fluctuation graphs
1 inrush current graph
