1.2 Features
16
Color LCD included
The instrument includes a 4.7-inch color STN liquid crystal display.
Numerical values, waveforms and graphs are clearly displayed.
Selectable display languages
Select English, Chinese, Japanese, or other language display text. Help
messages describing the settings appear in the selected language
Selectable channel (input terminal) colors
Select from five channel color schemes.
Match the screen display colors (waveforms, vectors and numerical val-
ues) to the input terminal and measurement lead labels.
AC adapter and rechargeable battery pack included
The AC adapter and NiMH rechargeable battery pack are included as
standard accessories. The battery can be charged whether the instru-
ment is turned on or off, and powers the instrument for up to six hours of
continuous operation.
Hand-held design
The instrument weighs only 1.2 kg, and the rubber grip makes it comfort-
ably hand portable.
USB 2.0 interface and PC application program for Model 3197
are included
The instrument can be remotely controlled, and data can be transferred
and analyzed on a computer using the supplied USB cable and special-
purpose PC application programs.
Detect wiring connections
Detection of phases, disconnected voltage cords and reverse-connected
clamp sensors can be determined from the Wiring Confirmation screen,
so miswiring can be avoided when measuring.
Optional data analysis application programs
Detailed analysis of measurement data recorded by the instrument is
available with the optional Model 9624-50 PQA-HiView PRO data analy-
sis application programs.
