Hioki 3197 User Manual

Contents
v
1
2
3
4
5
6
7
8
9
A
Index
9.1 Troubleshooting .......................................................163
9.2 Cleaning ...................................................................165
9.3 Battery Pack Replacement and Disposal .................166
9.4 Disposing of the Instrument .....................................167
Appendix ___________________________________ A1
Appendix 1 Interval and Recording Time Settings ........................ A1
Appendix 2 Relation Between Graph Divisions and Time ............. A5
Appendix 3 3197 Data-header Composition.................................. A7
Appendix 4 Displayed and Measurement Ranges ........................ A8
Appendix 5 Power Range Structure .............................................. A9
Appendix 6 Clamp Sensor Combined Accuracy.......................... A10
Appendix 7 How to Resolve USB Data Transfer Problems......... A11
Appendix 8 List of Settings (Default Settings) ............................. A13
Appendix 9 Definitions................................................................. A14

Detecting Anomalies and Phenomena Due to Drops in
Power Quality .................................................................. A14
 Power Measurement by the Two-Meter Method, and U3,
I3 Measurement Theory ..................................................A16
 Terminology ..................................................................... A18
Index __________________________________ Index 1

Hioki 3197 Specifications

General

Model	Hioki 3197
Category	Power Quality Analyzer
Harmonic Measurement	Up to 50th order
Display	LCD
Interface	RS-232C
Power Supply	100 to 240 V AC, 50/60 Hz
Measurement Category	CAT III 600 V
Current Measurement Range	With clamp sensor, up to 5000 A
Frequency Measurement Range	40 Hz to 70 Hz
Frequency Range	40 Hz to 70 Hz
