4 - 14
Figure 4.2.3-3 Taking Out the Specimen Stub Assembly
4. Exchange the specimen, and insert the specimen stub assembly, with its height already
adjusted, securely into the holder base of the stage until it stops.
Figure 4.2.3-4 Attaching the Specimen Stub Assembly
Figure 4.2.3-5 Hexagon Socket Head Screw for Fixing Specimen Stub Assembly
Specimen stub assembly
Hexagon socket head screw
Stage
Specimen stub assembly
To Next Page
