4 - 75
3. After image capture, the Save Image window will appear. Enter the file name, and save
the data by selecting the destination of save and the desired file type. If not saving the
image, click the [Cancel] button.
NOTE
: Any of the following characters cannot be used in a file name: [ / : ; * ? " < > | ! ' &]
(half-width characters).
Figure 4.3.14-4 Save Image Window
NOTE
: The items previously selected in the Setting for Save window (see Figure 4.3.28)
are displayed in the Information / comment area (see 4.3.2). To modify the
condition, click the [Edit] button (see 4.3.27) or select [Setting for Save] from the
[File] menu
4.3.15 Save Button
Figure 4.3.15-1 Save Button
A high-resolution image is captured and saved as an image file.
Image Save size: 1280x960 pixels (image only), 1280x1040 pixels (image + information),
1280x1100 pixels (image + information + comments)
Image save format: JPEG (*.jpg), bitmap (*.bmp), TIFF (*.tif)
