Appendix - 4
APPENDIX 2 List of Messages
The table below summarizes messages that can potentially appear when using 3D-Image
Capture and 3D-Image Viewer.
If an error occurs in a condition other than those shown below, stop the operation of the
system. Turn off the TM3030Plus main unit, and restart it.
If the problem is not resolved or the error persists even after the restart, please contact the
Service Department.
Message States Solutions
Time has run out.
Failed "Image Capture".
During Image Capture,
time (200 sec.) has run
out.
Close any other application that
may be running. Refrain from
performing any non-TM3030Plus
PC operations, such as Windows
file operations, external
communications, network
connections, or writing to a CD-R.
Time has run out.
Failed "Quick Save".
During Quick Save, time
(60 sec.) has run out.
Memory size is
inadequate.
Failed to save the
images.
The save destination disk
is full.
Check the amount of the disk
space. 3D-Image Capture
requires the space of at least 40
MB.
Failed the Brightness
setting.
The images with
inappropriate brightness
for 3D might be saved.
Do you continue?
Brightness could not be set
at the proper level.
Adjust the brightness using a
usual observation image.
If selecting [OK], Image Capture
will be executed without
automatic adjustment of the
brightness.
The focus is out of its
range.
Adjust the specimen
height properly.
Do you continue?
The value of D is out of the
recommended range of 8.5
1.0 mm.
Adjust specimen height so that
the value of D will be within the
range of 8.5
1.0 mm.
Electron beam is off.
Failed to start the
3D-Image capturing.
HV turned off (HV-OFF)
right before the 3D image
capturing due to
deterioration of the degree
of vacuum.
Click the [Start] button to perform
3D-Image Capture again.
