Honeywell MX7 Tecton User Manual

7 - 8
Reconnect
Note: These options can still be checked or unchecked whether Bluetooth connection is enabled or disabled.
Options
Option Function
Report when connection
lost
This option is Enabled (checked) by default.
There may be an audio or visual signal when a connection between a paired, active device is
lost.
A visual signal may be a dialog box placed on the display notifying the user the connection
between one (or all) of the paired Bluetooth devices has stopped. Tap the OK button to remove
the dialog box from the screen.
Report when reconnected This option is Disabled (unchecked) by default.
There may be an audio or visual signal when a connection between a paired, active device is
made.
A visual signal may be a dialog box placed on the display notifying the user the connection
between one (or all) of the paired Bluetooth devices has resumed. Tap the ok button to remove
the dialog box from the screen.
Report failure to recon-
nect
This option is Enabled (checked) by default.
The default time delay is 30 minutes. This value cannot be changed by the user.
There may be an audio or visual signal when a connection between a paired, active device
fails to re-connect. A visual signal may be a dialog box placed on the display notifying the user
the connection between one (or all) of the previously paired Bluetooth devices has failed.
Tap the X button or ok button to close the dialog box.
Possible reasons for failure to reconnect: Timeout expired without reconnecting; attempted to
pair with a device that is currently paired with another device; attempted to pair with a known
device that moved out of range or was turned off; attempted to pair with a known device but
the reason why reconnect failed is unknown.
Clear Pairing Table on
Boot
This option is Disabled (unchecked) by default.
When enabled (checked), all previous paired information is deleted upon any reboot sequence
and no devices are reconnected.
When enabled (checked) Auto Reconnect on Boot is automatically disabled (dimmed).
Auto Reconnect on Boot This option is Enabled (checked) by default. All previously paired devices are reconnected
upon any reboot sequence.
When disabled (unchecked), no devices are reconnected upon any reboot sequence.

Honeywell MX7 Tecton Specifications

General

Display diagonal	3.5 \
Display resolution	240 x 320 pixels
Display number of colors	-
Internal memory	0.256 GB
Internal memory type	RAM
Compatible memory cards	SD
Maximum memory card size	4 GB
Processor family	PXA 320
Processor frequency	0.806 GHz
GPS (satellite)	No
Operating system installed	Windows CE 6.0
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.0+EDR
Headphone outputs	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 100 %
Battery capacity	2200 mAh
AC adapter output current	7.4 A
Product color	Black, Blue
Keyboard layout	Alphanumeric
Linear (1D) barcodes supported	Codabar, Code 128, Code 39, Code 93, EAN-13, GS1-128 (UCC/EAN-128), PLANET, Plessey, Telepen, Trioptic, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR Code

Weight and Dimensions

Depth	50 mm
Width	86 mm
Height	223 mm
Weight	595 g
