Honeywell MX7 Tecton User Manual

5 - 23
Personal Panels
About Info (or About LXE)
The data cannot be edited by the MX7 Tecton user on these panels.
Software
The Software tab may display the current language. All languages are built into the OS image; English, French, Ger-
man, Simplified Chinese, Traditional Chinese, Japanese, Korean, Spanish, Thai. .
Hardware
The Hardware tab displays hardware information such as CPU, keyboard type, display and memory.
Version
The Versions tab displays the versions of many of the software programs installed. Not all installed software installed
on the MX7 Tecton is included in this list and the list varies depending on the applications loaded on the MX7 Tecton.
The Image line displays the revision of the system software installed. Refer to the last three digits to determine the revi-
sion level.
Version window information is retrieved from the registry.
Modify the Registry using the Registry Editor. Use caution when editing the Registry and make a backup copy of the
registry before changes are made.
The registry settings for the Version tab are under HKEY_LOCAL_MACHINE \ Software \ LXE \ Version in the registry.
To add a user application to the Version panel, create a new string value under the HKLM\Software\LXE\Version key.
The string name should be the Application name to appear in the Version window. The data for the value should be the
version number to appear in the Version window .
Version strings can be equal to or less than 254 characters. Because the strings are displayed in a text box, any num-
ber can be accommodated, up to the 64K byte text box limitation.
Network
The Network IP tab displays the MAC address of the network adapter(s) plus IP address and gateway for connected
adapters.
Tab Contents
Software GUID, Windows CE Version, OAL Version, Bootloader Version, Compile Ver-
sion, Programmable Component Version(s) and Language. Language indicates
localized version.
Hardware CPU Type, Codec Type, Display, Flash memory, and DRAM memory
Versions Revision level of software modules and .NET Compact Framework Version.
Utilities, Drivers, Image, CE API, and Internet Explorer.
Network IP Current IP address, MAC address, and gateway address for all network ports
(802.11 radio, ActiveSync).

Honeywell MX7 Tecton Specifications

General

Display diagonal	3.5 \
Display resolution	240 x 320 pixels
Display number of colors	-
Internal memory	0.256 GB
Internal memory type	RAM
Compatible memory cards	SD
Maximum memory card size	4 GB
Processor family	PXA 320
Processor frequency	0.806 GHz
GPS (satellite)	No
Operating system installed	Windows CE 6.0
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.0+EDR
Headphone outputs	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 100 %
Battery capacity	2200 mAh
AC adapter output current	7.4 A
Product color	Black, Blue
Keyboard layout	Alphanumeric
Linear (1D) barcodes supported	Codabar, Code 128, Code 39, Code 93, EAN-13, GS1-128 (UCC/EAN-128), PLANET, Plessey, Telepen, Trioptic, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR Code

Weight and Dimensions

Depth	50 mm
Width	86 mm
Height	223 mm
Weight	595 g
