11 - 2
Summit Tray Icon
The Summit tray icon is displayed when:
The Summit radio is installed and active
The Windows Zero Config utility is not active
The Tray Icon setting is On
Tap the icon to launch the SCU. Use the tray icon to view the radio status:
Using Windows Mobile Wireless Manager
Using the Summit Client Utility to manage wireless connectivity is recommended. However, if desired, Windows Mobile
includes the Wireless Manager utility to manage wireless network connections in place of the Summit Client Utility.
To use the Windows Mobile Wireless Manager, first open the Summit Client Utility.
1. Select ThirdPartyConfig in the Active Profile drop down box on the Main (page 11-5).
2. A message appears that a Power Cycle is required to make settings activate properly.
3. Tap OK.
4. Open the Registry (page 5-45) panel and tap Warmboot.
Access the Wireless Manager utility by tapping the radio icon at the top of the screen or tapping Start > Settings > Con-
nections > Wi-Fi.
If the Wi-Fi icon is not present in the Connections panel, return to the Summit Client Utility and select ThirdPartyConfig.
Refer to the Windows Mobile help screens or online documentation for configuring wireless security using the Windows
Mobile Wireless Manager.
The Summit tray icon provides access to the SCU and is a visual indicator of radio status.
The radio is not currently associated or authenticated to an Access Point
The signal strength for the currently associated/authenticated Access Point is less than -90 dBm
The signal strength for the currently associated/authenticated Access Point is -71 dBm to -90 dBm
The signal strength for the currently associated/authenticated Access Point is -51 dBm to -70 dBm
The signal strength for the currently associated/authenticated Access Point is greater than -50 dBm
