10 - 4
User Interface
The Enabler can be configured and controlled manually through the user interface on the MX7 Tecton. This section details the
functionality that can be controlled by the user or system administrator.
Screen displays shown in this section are designed to present the end-user with information graphically.
Information on the screen displays may be split between one or many tabbed panels.
Standard Avalanche Enabler parameters that are not supported may be missing or dimmed (visible but unable to be edited) on
the tabbed panels or screen displays.
Enabler Configuration
Depending on the version of the Enabler running on the MX7 Tecton, the desktop Enabler icon may look like one of the fol-
lowing:
The Enabler user interface application is launched by tapping either the Enabler Settings icon on the desktop or Taskbar or
by selecting Avalanche Enabler from the Programs menu.
The opening screen presents the MX7 Tecton user with the connection status and a navigation menu.
Note: Some parameters and features described in this section may not be available if you do not have the latest version of
the Enabler. Contact Technical Assistance (page 16-1) for upgrades.
or
Enabler Settings Icon
To Next Page
