Installing or Removing Vehicle Cradle Adapter Cup and Top Adapter
Equipment Required -- Phillips screwdriver and torquing tool (not supplied by Honeywell). You will need a torquing tool
capable of torquing up to 6 in/lb (+/- .5 in/lb) for the cradle adapter cup.
Install or remove the adapter on a clean, well-lit stable surface. The vehicle cradle is shipped with the cradle Adapter Cup
and Retainer Insert pre-installed.
The MX7 Tecton cradle charging pocket, without a cradle adapter cup and top adapter, is designed for an MX7 Tecton with
a rubber boot (MX7490BOOT or MX7491BOOT) enclosing/protecting the MX7 Tecton.
Before docking an MX7 Tecton without a rubber boot in the vehicle cradle, install the vehicle cradle Adapter Cup and
Retainer Cap Insert.
