Honeywell MX7 Tecton User Manual

11 - 1
11
Wireless Network Configuration
Introduction
The Summit client device is a Summit 802.11a/b/g radio, capable of 802.11a, 802.11b and 802.11g data rates. The radio can be
configured for no encryption, WEP encryption or WPA security.
Security options supported are:
• No Security (page 11-21)
• WEP (page 11-22)
• LEAP (page 11-23)
• WPA PSK (page 11-35)
• WPA/LEAP (page 11-29)
• PEAP/MSCHAP (page 11-25)
• PEAP/GTC (page 11-27)
• EAP-TLS (page 11-33)
• EAP-FAST (page 11-31)
Important Notes
After making any changes to the wireless configuration, perform a Suspend/Resume on the MX7 Tecton.
Summit Client Utility
Note: When making changes to profile or global parameters, tap the power key to place the MX7 Tecton in Suspend. When the
MX7 Tecton resumes from suspend the parameters are applied. The MX7 Tecton can be resumed by tapping the power
key or the touch screen or by pressing any key.
Select the Summit Client Utility using the Start button or tap the Summit Tray Icon (if present).
The Main (page 11-5)provides information, admin login and active profile selection.
Profile specific parameters are found on the Profile (page 11-8). The parameters on this tab can be set to unique values for each
profile.
The Status (page 11-11) contains information on the current connection.
The Diags (page 11-12) provides utilities to troubleshoot the radio.
Global parameters are found on theGlobal (page 11-13). The values for these parameters apply to all profiles.
Help
Help is available by tapping the ? icon in the title bar on most Summit Client Utility (SCU) screens.
Help may also be accessed by selecting Start > Help and tapping the Summit Client Utility link. The SCU does not have to
be open to view the help information using this option.
It is important that all dates are correct on the MX7 Tecton and host computers when using any type of certificate. Cer-
tificates are date sensitive and when the date is not correct authentication will fail.
It may be necessary to upgrade radio software in order to use certain Summit Client Utility (SCU) features. Contact
Technical Assistance (page 16-1) for details.
When using the 802.11a radio, the U-NII 1 band is the preferred band for indoor operation. For regulatory domains in
which the U-NII 3 band is allowed, the following channels are supported: 149, 153, 157 and 161. The AP must be con-
figured accordingly.
!
!
!

Honeywell MX7 Tecton Specifications

General

Display diagonal	3.5 \
Display resolution	240 x 320 pixels
Display number of colors	-
Internal memory	0.256 GB
Internal memory type	RAM
Compatible memory cards	SD
Maximum memory card size	4 GB
Processor family	PXA 320
Processor frequency	0.806 GHz
GPS (satellite)	No
Operating system installed	Windows CE 6.0
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.0+EDR
Headphone outputs	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 100 %
Battery capacity	2200 mAh
AC adapter output current	7.4 A
Product color	Black, Blue
Keyboard layout	Alphanumeric
Linear (1D) barcodes supported	Codabar, Code 128, Code 39, Code 93, EAN-13, GS1-128 (UCC/EAN-128), PLANET, Plessey, Telepen, Trioptic, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR Code

Weight and Dimensions

Depth	50 mm
Width	86 mm
Height	223 mm
Weight	595 g
