5 - 24
Buttons
Program Buttons
Program buttons can be used to assign functions to certain keys such as F1 through F5 and the diamond keys. Buttons
can only be assigned to programs that have an icon in the Start menu or the Settings folder (including sub-folders). A
program that is not in the above mentioned locations does not show up in the list here.
Note: The button links to the shortcut to the program, not the executable file.
Note: The System Administrator uses the Buttons setting panels to assign a Status User key and a Status Admin key
on the Status Popup panel, see Status Popup (page 5-41).
Setting Default
32-Key Keypad
F1 Left Softkey
F2 Right Softkey
F3, F4, F5, D1, D2, D3 <None>
55-Key Keypad
F1 Left Softkey
F2 Right Softkey
F3, F4, F5, D1 <None>
To assign a button:
1. Tap to highlight the desired button.
2. Select the program or shortcut from the Assign a
program drop down box.
3. Tap ok.
