Honeywell MX7 Tecton User Manual

7 - 1
7
Bluetooth Configuration
Introduction
Contact Technical Assistance (page 16-1) for upgrade availability if your Bluetooth panels are not the same as the panels pre-
sented in this section.
Discover and manage pairing with nearby Bluetooth devices.
MX7 Tecton Bluetooth client icon state and paired Bluetooth device icon states change as Bluetooth devices are discovered,
paired, connected and disconnected. There may be audible or visual signals as paired devices re-connect with the MX7 Tecton.
• The default Bluetooth setting is Off.
• The MX7 Tecton cannot be discovered by other Bluetooth devices when the Computer is discoverable option is disabled
(unchecked) on the Settings panel.
• Other Bluetooth devices cannot be discovered if they have been set up to be Non-Discoverable or Invisible.
• When Filtered Mode is enabled, the MX7 Tecton can pair with one Bluetooth scanner and one Bluetooth printer.
• When Filtered Mode is disabled, the MX7 Tecton can pair with up to four Bluetooth devices connected at the same time.
• It is not necessary to disconnect a paired scanner and printer before a different scanner or printer is paired with the MX7
Tecton.
• The target Bluetooth device should be as close as possible (up to 32.8 ft/10 meters Line of Sight) to the MX7 Tecton during
the pairing process.
Assumption: The System Administrator has Discovered and Paired targeted Bluetooth devices for the MX7 Tecton. The MX7
Tecton operating system has been upgraded to the revision level required for Bluetooth client operation. An application (or API)
is available that will accept data from serial Bluetooth devices.
Initial Configuration
1. Open the Bluetooth control panel or tap the Bluetooth icon.
2. Tap the Settings (page 7-6) Tab.
Setting Default
Discovered Devices None
Settings
Turn On Bluetooth Disabled / default is Off
Computer is connectable Enabled
Computer is discoverable Disabled
Prompt if devices request to pair Enabled
Continuous search Disabled
Filtered Mode Enabled
Printer Port on COM9: Disabled (unchecked) by default in both Filtered and Non Fil-
tered Modes. The option is dimmed in Non Filtered Mode.
Logging Disabled
Computer Friendly Name [System Name]
Reconnect
Report lost connection Enabled
Report when reconnected Disabled
Report failure to reconnect Enabled
Clear Pairing Table on boot Disabled
Auto Reconnect on Boot Enabled
Auto Reconnect Enabled

Honeywell MX7 Tecton Specifications

General

Display diagonal	3.5 \
Display resolution	240 x 320 pixels
Display number of colors	-
Internal memory	0.256 GB
Internal memory type	RAM
Compatible memory cards	SD
Maximum memory card size	4 GB
Processor family	PXA 320
Processor frequency	0.806 GHz
GPS (satellite)	No
Operating system installed	Windows CE 6.0
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.0+EDR
Headphone outputs	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 100 %
Battery capacity	2200 mAh
AC adapter output current	7.4 A
Product color	Black, Blue
Keyboard layout	Alphanumeric
Linear (1D) barcodes supported	Codabar, Code 128, Code 39, Code 93, EAN-13, GS1-128 (UCC/EAN-128), PLANET, Plessey, Telepen, Trioptic, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR Code

Weight and Dimensions

Depth	50 mm
Width	86 mm
Height	223 mm
Weight	595 g
