Installing the Adapter
Charging Pocket Adapter Cup
The adapter cup is installed facing in one direction.
1. Slip the adapter cup into the cradle charging pocket, aligning the screw hole in the adapter cup with the screw hole
in the charging bay.
2. Using a torquing screwdriver, insert the screw in the adapter cup screw hole, and torque the screw to 6 in/lbs +/- .5
in/lbs.
Retainer Insert
The Retainer Insert has three tabs.
