Honeywell touchpoint Pro Technical Handbook

TECHNICAL SPECIFICATIONS
Part. No. 2400M2501_6 Touchpoint Pro
171 Technical Handbook
21.4.6 Uninterruptible Power Supply Module (UPS)
Description
23.3 VDC – 30 VDC
Input Current
70 mA typical internal current consumption
Current consumption for battery charging in constant current mode at 24V input
1.7 A typical at battery selector position <10Ah
3.4 A typical at battery selector position >10Ah
Output Voltage
DC 24 V (nominal) in Normal Operation
Adjustable in Battery Operation
Output Current
Max. 25 A in Normal Operations min. 20 A in Battery Operation
Allowed Batteries
2 x 12 V
3.9 Ah – 130 Ah
VRLA (sealed lead acid) type
Dimension
46 mm x 124 mm x 127 mm (W x H x D)
Operating Temperature
–40 °C to +70 °C
Operating Humidity
5 to 95 %RH (non–condensing)
De–rating 60 °C to 70 °C
0.5 A / ºC
Storage Conditions
–40 °C to +85 °C, 5 to 95 %RH (non-condensing)
21.4.7 Backup Batteries
Description
2 x 12 V (24 V nominal) sealed lead acid batteries
Battery type
FIAMM 12 V 12 Ah FG21202 or 12 V 27 Ah FG22703
Dimensions
395 mm x 300 mm x 215 mm (W x H x D)
Weight
15.7 kg (12 Ah) / 25 kg (27 Ah)
Operating Temperature
–20 °C to +45 °C
Operating Humidity
10 to 90 %RH non condensing
Storage conditions
–20 °C to +40 °C, 10 to 90 %RH
Storage Lifetime without re–
charge
18 months at <5 °C, 6 months at 25 °C, 3 months at 30 °C, 2 months at 40 °C
Ingress Protection
IP20, NEMA Code 1
Input Voltage (charging)
25 VDC to 28 VDC (UPS Supervised)
Output Voltage (when supplying)
20 VDC to 28 VDC (dependent on charge level)
Maximum Input Current
3 A
Maximum Output Current
20 A
Environmental Protection Class
Equipment Class III, Installation Cat 2, Pollution Degree 2
Fuse type (inline)
Bussman 20 A Fast Acting Type ABC–20–R – 1¼’ x ¼’ Ceramic Tube
Current Limit Protection
Double pole circuit breaker / Isolator, 20 A
Maximum Altitude
2000 m (6562 feet)
