Honeywell touchpoint Pro Technical Handbook

TECHNICAL SPECIFICATIONS
Part. No. 2400M2501_6 Touchpoint Pro
176 Technical Handbook
21.6.5 Relay Output Module
Description
4–channel Relay Output Module incorporating 4 single pole change over (SPCO)
relays and 24 VDC Auxiliary Power Output
Electrical Connection
4 x SPCO Relay Terminals (TB1 to TB4)
4 x two-wire Auxiliary Output Terminals (TB5 to TB8)
Supply Voltage (Vs)
18 – 32 VDC
Auxiliary Supply Voltage
Supply Voltage (Vs) – 0.7 V
Auxiliary Supply Current
Maximum 1.5 A
Power Consumption
Maximum 1.5 W (excluding auxiliary power consumption)
Power Dissipation
Maximum 2.3 W
Relay Contacts (TB1–TB4)
Maximum 5 A through one relay contact at 250 VAC / 30 VDC (non–inductive)
Maximum 8 A total through all four relay contacts at 250 VAC / 30 VDC (non–
inductive) Minimum 12 VDC, 10 mA
Connector Coding
Relay output connectors (TB1–TB4) and auxiliary output connectors (TB5–TB8)
have coding keys to avoid incorrect wiring
The relay output connectors (TB1–TB4) are coloured black to identify them
for AC supply wiring
