Honeywell touchpoint Pro Technical Handbook

CONFIGURATION
Part. No. 2400M2501_6 Touchpoint Pro
80 Technical Handbook
9.3.15 Signal Range Fault Settings
Access Level: Engineer
Parameter Name
Default Setting
Value Range
Comment
Signal Under Range
Limit
-50 mV
-90 to -5 mV
The ‘Signal Under Range Fault’ will be set if the
sensor signal reading is less than the configured
‘Signal Under Range Limit’.
Signal Under Range
Latch
Latching
Non-Latching /
Latching
Signal Over Range
Limit
300 mV
25 to 360 mV
The ‘Signal Over Range Fault’ will be set if the
sensor signal reading is greater than the
configured ‘Signal Over Range Limit’.
Signal Over Range
Latch
Latching
Non-Latching /
Latching
9.3.16 Gas Range Fault Settings
Access Level: Engineer
The ‘Gas Under Range Fault’ will be set if the calculated gas concentration is less than the configured ‘Gas Under Range
Limit’. This fault may be due to the sensor signal drifting below the normal zero operating point.
Parameter Name
Default Setting
Value Range
Minimum
Maximum
Under Range Fault
Limit
Gas Range Min- 0.10 * (Gas
Range Max- Gas Range Min)
Gas Range Min – 0.24 * (Gas
Range Max - Gas Range Min)
Gas Range Min
Under Range Fault
Latch
Latching
Non-Latching / Latching
The ‘Over Range Limit Warning’ will be set if the calculated gas concentration is greater than the configured limit.
Note: If the Over Range Warning signal is latched, an extra Reset operation is required. The first Reset clears the over
range warning, the second reset clears any other conditions.
Parameter Name
Default Setting
Value Range
Minimum
Maximum
Over Range Warning
Limit
Gas Range Max+ 0.10 * (Gas
Range Max- Gas Range Min)
Gas Range Min
Gas Range Max+ 0.25 * (Gas
Range Max- Gas Range Min)
Over Range Warning
Latch
Latching
Non-Latching / Latching
9.3.17 Calibration Reminder Settings
Access Level: Engineer
Parameter Name
Default
Setting
Value Range
Comment
Calibration Reminder
Enable
Disabled
Enabled /
Disabled
‘Calibration Overdue Warning’ is set if the
‘Calibration Reminder Interval’ is exceeded.
Calibration Reminder
Interval
6 months
1 to 24 months
Calibration reminder is calculated to the day, e.g. if
the reminder is set on 27 January for 6 months’
time, the calibration overdue reminder will appear
on 27 July.
Note: Once the Calibration Overdue Warning is active, it can only be cleared by calibrating the channel.
