HP 1910 User Manual

238
Figure 205 Modifying LLDP settings on a port
3. Modify the LLDP parameters for the port as described in Table 76.
4. Click Apply.
A progress dialog box appears.
5. Click Close on the progress dialog box when the progress dialog box prompts that the
configuration succeeds.
Table 76 Configuration items
Item Descri
p
tion
Interface Name Displays the name of the port or ports you are configuring.
DLDP State
Displays the LLDP enabling status on the port you are configuring.
This field is not available when you batch-configure ports.

HP 1910 Specifications

General

Model	HP 1910
Category	Switch
Port Type	10/100/1000BASE-T
Layer	Layer 2
PoE Support	No
MAC Address Table Size	8K entries
VLAN Support	Yes
Management	Web-based GUI
Switching Capacity	56 Gbps
Forwarding Rate	41.7 Mpps
Jumbo Frame Support	Yes
Ports	24
