HP 1910 User Manual

239
Item Descri
p
tion
Basic
Settings
LLDP Operating Mode
Set the LLDP operating mode on the port or ports you are configuring.
Available options include:
• TxRx—Sends and receives LLDPDUs.
• Tx—Sends but not receives LLDPDUs.
• Rx—Receives but not sends LLDPDUs.
• Disable—Neither sends nor receives LLDPDUs.
Encapsulation Format
Set the encapsulation for LLDPDUs. Available options include:
• ETHII—Encapsulates outgoing LLDPDUs in Ethernet II frames and
processes an incoming LLDPDU only if its encapsulation is Ethernet
II.
• SNAP—Encapsulates outgoing LLDPDUs in Ethernet II frames and
processes an incoming LLDPDU only if its encapsulation is Ethernet
II.
NOTE:
LLDP-CDP PDUs use only SNAP encapsulation.
CDP Operating Mode
Set the CDP compatibility of LLDP. Available options include:
• Disable—Neither sends nor receives CDPDUs.
• TxRx—Sends and receives CDPDUs
IMPORTANT:
To enable LLDP to be compatible with CDP on the port, you must enable
CDP compatibility on the Global Setup tab and set the CDP operating
mode on the port to TxRx.
LLDP Polling Interval
Enable LLDP polling and set the polling interval.
If no polling interval is set, LLDP polling is disabled.
With the polling mechanism, LLDP periodically detects local
configuration changes. If a configuration change is detected, an
LLDPDU is sent to inform the LLDP neighbors of the change.
LLDP Trapping
Set the enable status of the LLDP trapping function on the port or ports.
LLDP trapping is used to report to the network management station
critical events such as new neighbor devices detected and link failures.
NOTE:
To avoid excessive traps from being sent when topology is instable, you
can tune the minimum trap transit interval on the Global Setup tab.
Base TLV
Settings
Port Description Select to include the port description TLV in transmitted LLDPDUs.
System Capabilities Select to include the system capabilities TLV in transmitted LLDPDUs.
System Description Select to include the system description TLV in transmitted LLDPDUs.
System Name Select to include the system name TLV in transmitted LLDPDUs.
Management Address
Select to include the management address TLV in transmitted LLDPDUs
and in addition, set the management address and its format (a numeric
or character string in the TLV).
If no management address is specified, the main IP address of the
lowest VLAN carried on the port is used. If no main IP address is
assigned to the VLAN, 127.0.0.1 is used.

HP 1910 Specifications

General

Model	HP 1910
Category	Switch
Port Type	10/100/1000BASE-T
Layer	Layer 2
PoE Support	No
MAC Address Table Size	8K entries
VLAN Support	Yes
Management	Web-based GUI
Switching Capacity	56 Gbps
Forwarding Rate	41.7 Mpps
Jumbo Frame Support	Yes
Ports	24
