HP 1910 User Manual

246
Table 79 Field description
Field Descri
p
tion
Chassis type
Chassis ID representation:
• Chassis component.
• Interface alias.
• Port component.
• MAC address.
• Network address.
• Interface name.
• Locally assigned—Locally-defined chassis type other than those listed
above.
Port ID type
Port ID representation:
• Interface alias.
• Port component.
• MAC address.
• Network address.
• Interface name.
• Agent circuit ID.
• Locally assigned—Locally-defined port ID type other than those listed
above.
Port ID The port ID value.
System capabilities supported
The primary network function of the system:
• Repeater.
• Bridge.
• Router.
System capabilities enabled
The network function enabled on the system:
• Repeater.
• Bridge.
• Router.
Auto-negotiation supported The support of the neighbor for auto negotiation.
Auto-negotiation enabled The enable status of auto negotiation on the neighbor.
OperMau Current speed and duplex mode of the neighbor.
Power type
Power type:
• Type 1 PD—This type requires power from 0 to 15.4 W, a voltage
from 44 to 57 V, and a maximum current of 350 mA.
• Type 2 PD—This type requires power from 0 to 30 W, a voltage from
50 to 57 V, and a maximum current of 600 mA.
Power source
Power supply type for a PD:
• Unknown—Unknown power supply.
• PSE—PSE power supply.
• Local—Local power supply.
• PSE and local—PSE and local power supply.

HP 1910 Specifications

General

Model	HP 1910
Category	Switch
Port Type	10/100/1000BASE-T
Layer	Layer 2
PoE Support	No
MAC Address Table Size	8K entries
VLAN Support	Yes
Management	Web-based GUI
Switching Capacity	56 Gbps
Forwarding Rate	41.7 Mpps
Jumbo Frame Support	Yes
Ports	24
